Clunk fix assembly

2003.5_MSP

2003.5_MSP

Member
:
2003.5 MSP
I was wondering how to install the clunk fix on the msp... It came disassembled and with no install instructions from a member... Needless to say I'm 100% clueless on how to install and where to install... Is it used in conjunction with existing sway bar bushings or meant to replace them...

Any help will be appriciated, thanks

I don't know what type you have but I believe most of them are bolted to the rear subframe where the bushings were then you bolt the bushing bracket onto it. Some kits have a new bracket for the bushing.

Ok looks to answer 99% of my questions, but I bet I can figure it out... I'm just stumped on where to connect the longer pieces...

The long piece is a brace that runs from the top of the bracket to the original bushing mount point.


pw~mp5 said:
The long piece is a brace that runs from the top of the bracket to the original bushing mount point.
Click to expand...

OH ok it all makes sense now, it just moves the bushings out it looks like... and it looks like the long piece mounts under the main brace correct
